[T1R] Digital Level Mode Overview

The Digital Level is the third tool on the T1R Range, providing high-accuracy level readings within ±0.2°. It helps ensure surfaces, layouts, and installations are perfectly aligned.

Accessing the Digital Level

1. Press the Menu button to bring up the menu.
2. Using the arrow buttons, highlight the Level menu.
3. Press Menu  to enter the Level menu.
4. Using the arrow buttons, highlight the level mode you would like to use.
5. Press Menu enter the selection.

Level Modes

Level

Displays a single-axis level reading to help align surfaces horizontally or vertically.

Dual Level

Shows both horizontal and vertical leveling simultaneously for precise alignment in two directions.

Target Level

Allows you to set a desired angle or level reference point, then guides you visually to hit that exact target.

Post Level

Uses dual-axis leveling to check and align posts in either direction, quickly bringing them into position.

Single Axis Level on the Home View

When the Digital Level is active, a single axis level reading is displayed directly on the Home View, so you can reference your level status at a glance without navigating into the Level menu.
